MVI56E-MNETR module interface overview

MVI56E-MNETR is an enhanced network interface module manufactured by ProSoft Technology, mainly used for data transmission in industrial automation and control systems. The following are the main interfaces of the module and its functions:

1. Ethernet interface MVI56E-MNETR

10/100Mbps Ethernet configuration: The MVI56E-MNETR module is equipped with a 10/100Mbps Ethernet interface, supports automatic crossover detection, and can automatically adapt to straight-through or crossover Ethernet cables.

Automatic crossover detection: This feature simplifies network cabling and reduces installation and maintenance complexity.

2. ControlLogix backplane interface MVI56E-MNETR

Single-slot ControlLogix backplane: The MVI56E-MNETR module plugs directly into a slot on the ControlLogix backplane for seamless connection to the ControlLogix processor.

Remote rack type: This module supports remote rack applications with data transfer over Ethernet/IP or ControlNet networks.

3. Data transmission interface MVI56E-MNETR

Minimized input or output data image size: The MVI56E-MNETR module optimizes data transfer efficiency by reducing the input or output data image size, especially in remote rack applications.

Supports up to 100 client connection commands: This module can handle up to 100 client connection requests simultaneously, improving the flexibility and scalability of the system.

16-bit register network configuration: The module supports CIP-connected 16-bit register network configuration, which is suitable for a variety of industrial network environments.

4. Diagnosis and configuration interface MVI56E-MNETR

Built-in Web server: The MVI56E-MNETR module has a built-in Web server that allows users to access module status, diagnostic information, and firmware updates through a browser.

ProSoft Discovery Service (PDS): PDS is a software utility used to locate the MVI56E module on the network and assign a temporary IP address for easy configuration.

ProSoft Configuration Builder (PCB): PCB is a Windows-based graphical user interface software that provides simple product and network configuration.

4-Character Alphanumeric Scrolling LED: The LED on the module displays status and diagnostic information in plain English for quick problem identification and resolution.

5. Other interfaces MVI56E-MNETR

Supports Modbus TCP/IP: The MVI56E-MNETR module supports the Modbus TCP/IP protocol and can easily interface with Modicon Programmable Automation Controllers (PACs) and other Modbus TCP/IP compliant devices.
